بافر دوجهته
P82B96TD
Dual bi-directional bus buffe
کیفیت: ORIGINAL(distributor) پکیج: SOP-8
قیمت تک فروشی 1,178,000 ریال
قیمت عمده 1,122,000 ریال (10 به بالا)
قیمت ویژه 1,099,600 ریال (100 به بالا)
قیمت فوق العاده1,088,400 ریال (1000 به بالا)
![SKYTECH](bootstrap/img/Icon/tether.png) قیمت تک فروشی 1.734 تتر با تخفیف
10.5109.89.7
|
توضیحات
P82B96 يک آي سي دوقطبي است که يک رابط منطقي غيرقابل اتصال، دو طرفه و منطقي بين گذرگاه I2C معمولي و طيف وسيعي از پيکربنديهاي باس ديگر ايجاد ميکند. اين مي تواند سيگنال هاي منطقي I 2C-bus را به باس هاي مشابه با سطوح ولتاژ و جريان متفاوت متصل کند. به عنوان مثال، ميتواند به SMBus 350 µA، دستگاههاي منطقي 3.3 ولت، و سطوح 15 ولت و/يا خطوط کم امپدانس براي بهبود ايمني نويز در طولهاي باس بيشتر متصل شود. اين رابط بدون هيچ گونه محدوديتي در پروتکل هاي I2C-bus معمولي يا سرعت ساعت به دست مي آورد. IC حداقل بارگذاري را به گره باس I2C اضافه مي کند و بارگيري هاي گذرگاه جديد يا گره هاي گذرگاه I2C راه دور منتقل يا به گره محلي تبديل نمي شوند. محدوديتهاي تعداد دستگاههاي I2C-bus در يک سيستم، يا جداسازي فيزيکي بين آنها، عملاً حذف ميشوند. انتقال سيگنال هاي SDA و SCL از طريق خطوط انتقال متعادل (جفت پيچ خورده) يا با جداسازي گالوانيکي (کوپلينگ نوري) ساده است زيرا سيگنال هاي Tx و Rx جهت دار جداگانه ارائه مي شوند. سيگنالهاي Tx و Rx ممکن است مستقيماً بدون ايجاد قفل وصل شوند تا يک خط سيگنال دو طرفه جايگزين با ويژگيهاي I 2C-bus ارائه کنند.
Description
The P82B96 is a bipolar IC that creates a non-latching, bidirectional, logic interface
between the normal I2C-bus and a range of other bus configurations. It can interface
I
2C-bus logic signals to similar buses having different voltage and current levels.
For example, it can interface to the 350 µA SMBus, to 3.3 V logic devices, and to 15 V
levels and/or low-impedance lines to improve noise immunity on longer bus lengths.
It achieves this interface without any restrictions on the normal I2C-bus protocols or clock
speed. The IC adds minimal loading to the I2C-bus node, and loadings of the new bus or
remote I2C-bus nodes are not transmitted or transformed to the local node. Restrictions
on the number of I2C-bus devices in a system, or the physical separation between them,
are virtually eliminated. Transmitting SDA and SCL signals via balanced transmission
lines (twisted pairs) or with galvanic isolation (opto-coupling) is simple because separate
directional Tx and Rx signals are provided. The Tx and Rx signals may be directly
connected, without causing latching, to provide an alternative bidirectional signal line with
I
2C-bus properties
|
