BT815Q
کیفیت: نا مشخص پکیج:
قیمت تک فروشی 5,238,600 ریال
قیمت عمده 5,132,200 ریال (10 به بالا)
قیمت ویژه 5,030,056 ریال (100 به بالا)
قیمت فوق العاده4,978,984 ریال (1000 به بالا)
![SKYTECH](bootstrap/img/Icon/tether.png) قیمت تک فروشی 7.698 تتر با تخفیف
46.5545.644.6944.23
|
توضیحات
سري BT815/6 يک سري از کنترلر گرافيک ها براي ساخت HMIها با ويژگي هاي زير:
*موتور گرافيکي پيشرفته ي با رزولوشن گرافيکي بالا
*پشتيباني از کنترلر گرافيک وکنترل صدا و کنترل تاچ
*پشتياني از چند ويجت همزمان
*اينتراپت قابل برنامه ريزي براي اتصال به ميکروکنترلر
*اسيلاتور 12 مگاهرتز داخليبا چندبرابر کننده تا 72 مگاهرتز
کاربرد ها :
*تجهيزات امنيتي خانه ها
*مانيتورينگ ضربان قلب
*مانيتورينگ فشار خون
*ابزار الات
*کاربرد هاي پزشکي
Description
Bridgetek Pte Ltd BT815/6 Advanced Embedded Video Engine
The BT815/6 is a series of easy to use graphic
controllers targeted at embedded applications to
generate high-quality Human Machine Interfaces
(HMIs). It has the following features:
* Advanced Embedded Video Engine(EVE) with
high resolution graphics and video playback
*BT815/6 functionality includes graphic control,
audio control, and touch control interface.
*Support multiple widgets for simplified design
implementation
*Built-in graphics operations allow users with
little expertise to create high-quality displays
*Support Adaptive Scalable Texture Compression
(ASTC) format to save considerable memory
space for larger fonts and graphics images
*Support external QSPI NOR flash to fetch
graphic elements (image, font, widget etc.)
*Support 4-wire resistive touch screen (BT816)
*Support capacitive touch screen with up to 5
touches detection (BT815)
*Hardware engine can recognize touch tags and
track touch movement. Provides notification for
up to 255 touch tags.
*Enhanced sketch processing
*Programmable interrupt controller provides
interrupts to host MCU
*Built-in 12MHz crystal oscillator with PLL
providing programmable system clock up to
72MHz
*Video RGB parallel output; configurable to
support PCLK up to 60MHz and R/G/B output of
1 to 8 bits
*Programmable timing to adjust HSYNC and
VSYNC timing, enabling interface to numerous
displays
Typical Applications
*Point of Sales Machines
*Multi-function Printers
*Instrumentation
*Home Security Systems
*Graphic touch pad – remote, dial pad
*Tele / Video Conference Systems
*Phones and Switchboards
*Medical Appliances
*Blood Pressure displays
*Heart monitors
* Glucose level displays
|
