آی سی درایور موتور دو فاز
TB6562AFG
The TB6562ANG/AFG is a 2-phase bipolar stepping motor driver
کیفیت: ORIGINAL(distributor) پکیج:
قیمت تک فروشی 870,363 ریال
قیمت عمده 764,693 ریال (10 به بالا)
قیمت ویژه 749,899 ریال (100 به بالا)
قیمت فوق العاده742,502 ریال (1000 به بالا)
![SKYTECH](bootstrap/img/Icon/tether.png) قیمت تک فروشی 1.287 تتر با تخفیف
7.66.656.526.45
|
توضیحات
TB6562ANG/ يک ايسي درايور موتور 2 فاز ميباشد . بازده اين ايسي بخاطر مقاومت کم سوييچ ها در حد 1.5 اهم ، بالا ميباشد.
--از ويژگي هاي اين ايسي ميتوان به ترمال شات داون داخلي، محافظ اضافه جريان ،داراي مد پاور سيو ، جريان خروجي تا 1.5آمپر ، ولتاژ عملياتي 40 ولتي ، مدار کنترل PWM ، درايو بصورت 2-phase/1-2-phase/W 1-2-phase اشاره کرد.
Description
The TB6562ANG/AFG is a 2-phase bipolar stepping motor driver
that contains DMOS transistors in the output stage. The driver
achieves high efficiency through the use of low ON-resistance
DMOS transistors and PWM current control circuitry.
--Features:
**2-phase/1–2-phase/W 1–2-phase excitation
PWM current control
**Power supply voltage: 40 V (max)
**Output current: 1.5 A (max)
**Low ON-resistance: 1.5 Ohm(upper and lower transistors/typ.)
**Power-saving function
**Overcurrent protection: ILIM = 2.5 A (typ.)
**Thermal shutdown
|
