گیت درایور
MIC4425YM SOP8
The MIC4423/4424/4425 family are highly reliable BiCMOS/ DMOS buffer/driver/MOSFET drivers.
کیفیت: ORIGINAL(distributor) پکیج:
قیمت تک فروشی 633,504 ریال
قیمت عمده 512,803 ریال (10 به بالا)
قیمت ویژه 503,147 ریال (100 به بالا)
قیمت فوق العاده498,319 ریال (1000 به بالا)
 قیمت تک فروشی 0.899 تتر با تخفیف
4.83.843.763.72
|
توضیحات
mic4425ym جزو ايسي هاي بافر / درايور / براي درايو ملسفت ميباشد .mic4425ym ورژن جريان بالاتري از MIC4426 ميباشد که با هم مطابقت پين اوت دارند.
از ويژگي هاي اين ايسي درايور ميتوان به جريان خروجي تا 3 آمپر ، درايو 1800 پيکو فاراد در 25 نانو ثانيه ،ولتاژ عملياتي 4.5 تا 18 ولت ، کم مصرف و قابل اطمينان و ورودي لاجيک اشاره کرد.
Description
The MIC4423/4424/4425 family are highly reliable BiCMOS/
DMOS buffer/driver/MOSFET drivers. They are higher output current versions of the MIC4426/4427/4428, which are
improved versions of the MIC426/427/428. All three families
are pin-compatible. The MIC4423/4424/4425 drivers are capable of giving reliable service in more demanding electrical
environments than their predecessors. They will not latch
under any conditions within their power and voltage ratings.
They can survive up to 5V of noise spiking, of either polarity,
on the ground pin. They can accept, without either damage
or logic upset, up to half an amp of reverse current (either
polarity) forced back into their outputs.
--Features:
• Reliable, low-power bipolar/CMOS/DMOS construction
• Latch-up protected to >500mA reverse current
• Logic input withstands swing to –5V
• High 3A-peak output current
• Wide 4.5V to 18V operating range
• Drives 1800pF capacitance in 25ns
• Short <40ns typical delay time
• Delay times consistent with in supply voltage change
• Matched rise and fall times
• TTL logic input independent of supply voltage
• Low equivalent 6pF input capacitance
• Low supply current
|
