آپ امپ
MAX4181EUT
high-speed performance, low distortion, and excellent video specifications with ultra-low-power operation OP-AMP
کیفیت: ORIGINAL(distributor) پکیج: SOT23-6
قیمت تک فروشی 879,418 ریال
قیمت عمده 828,423 ریال (10 به بالا)
قیمت ویژه 812,105 ریال (100 به بالا)
قیمت فوق العاده803,946 ریال (1000 به بالا)
قیمت تک فروشی 1.38 تتر با تخفیف
8.167.687.537.45
|
توضیحات
MAX4181EUT يک ايسي اپ امپ در پکيج SOT23-6 ميباشد که در تصوير برداري پزشکي ، دستگاهاي مولتي مديا که از باطري تغذيه ميشوند ، دوربين هاي حرفه اي ، تلوزيون ها ، عکس برداري CCD ها ،سوييچ و مالتي پلکسينگ صدا و .... کاربرد دارد.
از ويژگي ها ان ميتوان به مصرف جريان پايين ، فرکانس عملياتي تا 270 مگاهرتز ، ولتاژ عملياتي 5 يا 5+- اشاره کرد.
Description
The MAX4180 family of current-feedback amplifiers
combines high-speed performance, low distortion,
and excellent video specifications with ultra-low-power
operation in miniature packages. They operate from
±2.25V to ±5.5V dual supplies, or from a single +5V
supply. They require only 1mA of supply current per amplifier while delivering up to ±60mA of output current
drive. The MAX4180/MAX4182/MAX4183/MAX4186
are compensated for applications with a closed-loop
gain of +2 (6dB) or greater, and provide a -3dB bandwidth of 240MHz and a 0.1dB bandwidth of 70MHz.
The MAX4181/MAX4184/MAX4185/MAX4187 are compensated for applications with a +1 (0dB) or greater
gain, and provide a -3dB bandwidth of 270MHz and a
0.1dB bandwidth of 60MHz.
|
