توضیحات
اين ماژول جهت فراهم کردن ارتباط بي سيم Wi-Fi به اينترنت باشد و از طريق پروتکل سريال با ميکروکنترلر ها ارتباط برقرار مي کند. با استفاده از اين ماژول مي توانيد پروژه ي خود را مجهز Wi-Fi کنيد.
ويژگي ها:
ولتاژ کاري:3.3 ولت
نوع ارتباط با ميکروکنترلر: پروتکل سريال UART
داراي آنتن روبردي
دو ورودي يا خروجي عمومي GPIO
تنظيمات از طريق فرامين AT Command
پشتيباني از پروتکل هاي اينترنتي مثل P2P , TCP/IP
جريان مصرفي پايين
قابل استفاده با بردهاي آردوينو و ساير ميکروکنترلر ها
کاربردها:
اتوماسيون خانگي
برنامه هاي پزشکي
کنترل و مانيتورينگ بي سيم
سيستم هاي هوشمند
دوربين هاي IP دار
سيستم هاي امنيتي
Description
This is WiFi serial transceiver module, based on ESP8266 SoC.
The SOC has Integrated TCP/IP protocol stack
We have a set of documents in Chinese. We are preparing tutorials and demo software to showcase utility of this module.
Please buy this module only when you understand the existing documents.
ESP8266 is a highly integrated chip designed for the needs of a new connected world. It offers a complete and self-contained Wi-Fi networking solution, allowing it to either host the application or to offload all Wi-Fi networking functions from another application processor.
ESP8266 has powerful on-board processing and storage capabilities that allow it to be integrated with the sensors and other application specific devices through its GPIOs with minimal development up-front and minimal loading during runtime. Its high degree of on-chip integration allows for minimal external circuitry, and the entire solution, including front-end module, is designed to occupy minimal PCB area.
Corresponding Interface:
SDIO 2.0, SPI, UART
32-pin QFN package
Integrated RF switch, balun, 24dBm PA, DCXO, and PMU
Integrated RISC processor, on-chip memory and external memory interfaces
Integrated MAC/baseband processors
Quality of Service management
I2S interface for high fidelity audio applications
On-chip low-dropout linear regulators for all internal supplies
Proprietary spurious-free clock generation architecture
Integrated WEP, TKIP, AES, and WAPI engines
Specification:
802.11 b/g/n
Wi-Fi Direct (P2P), soft-AP
Integrated TCP/IP protocol stack
Integrated TR switch, balun, LNA, power amplifier and matching network
Integrated PLLs, regulators, DCXO and power management units
+19.5dBm output power in 802.11b mode
Power down leakage current of <10uA
Integrated low power 32-bit CPU could be used as application processor
SDIO 1.1/2.0, SPI, UART
STBC, 1×1 MIMO, 2×1 MIMO
A-MPDU & A-MSDU aggregation & 0.4ms guard interval
Wake up and transmit packets in < 2ms
Standby power consumption of < 1.0mW (DTIM3)
|
