آی سی رابط RS485/RS-422
MAX3089EESD+T
15kV electrostatic discharge (ESD)-protected, high-speed transceivers for RS485/RS-422 communication
کیفیت: Bulk(فله ایی) پکیج: SOP-14
قیمت تک فروشی 1,214,478 ریال
قیمت عمده 1,106,344 ریال (10 به بالا)
قیمت ویژه 1,084,717 ریال (100 به بالا)
قیمت فوق العاده1,073,904 ریال (1000 به بالا)
![SKYTECH](bootstrap/img/Icon/tether.png) قیمت تک فروشی 1.788 تتر با تخفیف
10.569.69.419.31
|
توضیحات
MAX3089EESD+T جزو ايسي هاي محافظتي تخليه ي الکتريسيته ي ساکن براي پروتکول هاي ارتباطي RS485/RS-422 که از يک گيرنده و فرستنده تشکيل شده است ميباشد.
واسط هاي سريال مي توانند سطوح منطقي استاندارد را بين فرستنده و گيرنده ايجاد کنند ، محيط انتقال و کانکتورها و مشخصه زماني و نرخ داده را تعريف کنند. در برخي از موارد آنها مي توانند ارتباط سريال را به موازي و ارتباط موازي را به سريال تبديل کنند.
استاندارد RS در لايه فيزيکي ارتباط سريال به کار گرفته مي شوند. تعريف سطح منطقي ، محيط انتقال و کانکتورها بخش لايه فيزيکي (PHY) و يا لايه شماره 1 از مدل شبکه ميان ارتباطي باز يا OSI مخفف Open Systems Interconnection است. هر مورد اضافه مانند دستکاري داده ها بخش لايه کنترل دسترسي مياني (MAC) يا لايه 2 مدل OSI است.
Description
The MAX3080E–MAX3089E are ±15kV electrostatic discharge (ESD)-protected, high-speed transceivers for RS485/RS-422 communication that contain one driver and
one receiver. These devices feature fail-safe circuitry,
which guarantees a logic-high receiver output when the
receiver inputs are open or shorted. This means that the
receiver output will be a logic high if all transmitters on a
terminated bus are disabled (high impedance). The
MAX3080E/MAX3081E/MAX3082E feature reduced
slew-rate drivers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing
error-free data transmission up to 115kbps. The
MAX3083E/MAX3084E/MAX3085E offer higher driver
output slew-rate limits, allowing transmit speeds up to
500kbps. The MAX3086E/MAX3087E/ MAX3088Es’ driver slew rates are not limited, making transmit speeds
up to 10Mbps possible. The MAX3089E’s slew rate is
selectable between 115kbps, 500kbps, and 10Mbps by
driving a selector pin with a single three-state driver. All
devices feature enhanced ESD protection. All transmitter
outputs and receiver inputs are protected to ±15kV
using the Human Body Model.
|
