توضیحات
ماژول وايفاي ESP-WROOM-02 داراي هسته وايفاي ESP8266EX
داراي هسته داخلي 32 بيتي ( شما ميتوانيد مقداري از پردازش برنامه تان را روي اين چيپ تقسيم کنيد)
داراي ADC 10 بيت داخلي
پشتيباني از پروتکول TCP/IP
داراي چند برابر کننده فرکانس يا PLL
داراي رگولاتور ولتاژ و مدارات مديريت تغذيه
پشتيباني از HSPI ,UART,I2C , I2S ,PWM ,GPIO ,IR remote control
مصرف بسيار پايين در حد ميکرو امپر در حالت استندباي
Description
Built-in low-power 32 -bit CPU : You can double as an application processor
Built-in 10 bit precision ADC
Built-in TCP / IP protocol stack
Built TR switch, balun , LNA , power amplifier and matching network
Built-in PLL , voltage regulator and power management components
Supports antenna diversity
STBC , 1×1 MIMO , MIMO 2X1
A-MPDU , A-MSDU aggregation and 0.4 s guard interval
WiFi @ 2.4 GHz , supports WPA / WPA2 security mode
Support STA / AP / STA + AP mode
Support Smart Config function (including Android and iOS devices)
HSPI , UART , I2C , I2S , IR Remote Control , PWM , GPIO
Deep sleep to keep current 10 uA , shutdown current of less than 5 uA
? ms within the wake, connect and transfer data packets
??????b mode + 20 dBm of output power
Standby power consumption is less than 1.0 mW (DTIM3)
Chip Operating temperature range: -40 ° C – 125 °
|
