حافظه SRAM
CS18LV02565ACR55
High Speed Super Low Power SRAM
کیفیت: ORIGINAL(distributor) پکیج:
قیمت تک فروشی 2,259,400 ریال
قیمت عمده 2,153,000 ریال (10 به بالا)
قیمت ویژه 2,110,440 ریال (100 به بالا)
قیمت فوق العاده2,089,160 ریال (1000 به بالا)
![SKYTECH](bootstrap/img/Icon/tether.png) قیمت تک فروشی 3.323 تتر با تخفیف
19.951918.6218.43
|
توضیحات
حافظه "رم" (Random Access Memory) که به اختصار عموما آن را به نام RAM مي شناسيم، مهم ترين حافظه مورد استفاده در يک کامپيوتر و يا لپ تاپ است. حافظه هاي رم براي تمامي سيستم هاي پردازشي ديجيتالي، حتي در تلويزيون ها، مورد استفاده قرار مي گيرند. شرکت هايي نظير Micron، Samsung و SK Hynix به طور تخصصي در توليد تراشه هاي نيمه هادي رم، فعاليت گسترده داشته و بسياري از توليد کنندگان ماژول هاي رم، حافظه هاي خود را از اين شرکت ها تامين مي کنند.
Description
High Speed Super Low Power SRAM
--The CS18LV02565 is a high performance, high speed and super low power CMOS Static Random
Access Memory organized as 32,768 words by 8bits and operates for a single 4.5 to 5.5V supply voltage.
Advanced CMOS technology and circuit techniques provide both high speed, super low power features
and maximum access time of 55/70ns in 5.0V operation. Easy memory expansion is provided by an
active LOW chip enable (/CE) and active LOW output enable (/OE).
The CS18LV02565 has an automatic power down feature, reducing the power consumption
significantly when chip is deselected. The CS18LV02565 is available in JEDEC standard 28-pin TSOP I
(8x13.4 mm), SOP (330 mil) and PDIP (600 mil) packages.
? -FEATURES:
- Wide operation voltage : 4.5 ~ 5.5V
- Ultra low power consumption : 2mA@1MHz (Max.) , Vcc=5.0V.
-1.0 uA (Typ.) CMOS standby current
- High speed access time : 55/70ns.
- Automatic power down when chip is deselected.
- Three state outputs and TTL compatible.
- Data retention supply voltage as low as 1.5V.
- Easy expansion with /CE and /OE options.
|
