تصحیح کننده ضریب قدرت
UCC38500DW
Power Factor Correction - PFC BiCMOS PFC/PWM Comb Controller
کیفیت: ORIGINAL(distributor) پکیج: SOIC-20
قیمت تک فروشی 3,534,819 ریال
قیمت عمده 3,367,598 ریال (10 به بالا)
قیمت ویژه 3,300,710 ریال (100 به بالا)
قیمت فوق العاده3,267,265 ریال (1000 به بالا)
 قیمت تک فروشی 3.819 تتر با تخفیف
20.7919.819.419.21
|
توضیحات
خانواده UCC2850x تمام عملکردهاي کنترلي لازم براي پيش تنظيم کننده اصلاح شده با ضريب توان فعال و مبدل dc-to-dc مرحله دوم را فراهم مي کند. کنترلر با شکل دادن شکل موج جريان خط ورودي ac براي مطابقت با ولتاژ خط ورودي ac با استفاده از کنترل حالت جريان متوسط، ضريب توان نزديک به واحد را به دست مي آورد. مبدل dc- to-dc از کنترل حالت حداکثر جريان براي انجام گام به پايين استفاده مي کند
تبديل قدرت مرحله PFC مدوله شده است در حالي که مرحله دوم لبه انتهايي همگام شده است تا حداقل همپوشاني بين سوئيچ هاي بوست و PWM وجود داشته باشد. اين جريان موج دار در خازن خروجي حجيم را کاهش مي دهد. به منظور کار با بيش از سه به يک محدوده ولتاژ خط ورودي، از يک خط تغذيه (VFF) براي ثابت نگه داشتن توان ورودي با ولتاژ ورودي متغير استفاده مي شود. توليد VFF با استفاده از IAC در ارتباط با فيلتر تک قطبي خارجي انجام مي شود. اين نه تنها تعداد قطعات خارجي را کاهش مي دهد، بلکه از استفاده از قطعات ولتاژ بالا نيز جلوگيري مي کند و راه حلي کم هزينه را ارائه مي دهد. سپس ضريب جريان خط را بر مربع VFF تقسيم مي کند
Description
The UCC2850x family provides all of the control functions necessary for an active power- factorcorrected preregulator and a second-stage dc- to- dc converter. The controller achieves near-unity power factor by shaping the ac input line current waveform to correspond to the ac input-line voltage using average current-mode control. The dc-to-dc converter uses peak current-mode control to perform the step-down
power conversion. The PFC stage is leading-edge modulated while the second stage is trailing-edge synchronized to allow for minimum overlap between the boost and PWM switches. This reduces ripple current in the bulk-output capacitor.In order to operate with over three-to-one range of input-line voltages, a line feedforward (VFF) is used to keep input power constant with varying input voltage. Generation of VFF is accomplished using IAC in conjunction with an external single-pole filter. This not only reduces external parts count, but also avoids the use of high-voltage components, offering a lower-cost solution. The multiplier then divides the line current by the square of VFF
|
